So, titanium dioxide (TiO2) photoelectrode is considered very close to an ideal semiconductor for photoelectrode because of its high stability in seawater, low cost and safety toward both humans and the environment. Chapter 3 demonstrate an efficient photoelectrochemical-assisted rechargeable seawater battery (Figure 14). By integrating TiO2 nanostructure-based photoelectrodes with the seawater batteries, we can achieve significant enhancement of the voltage efficiency during the charging/discharging processes. Moreover, TiO2 nanostructures showed excellent photoelectrochemical performances in seawater in association with the efficient photocharging. Hence, the outcome of this research can provide a systematic study of potentially active materials, photoelectrodes used in solar seawater batteries and their effectiveness on the electrochemical performances. Figure 12. Schematic illustration of photoelectrochemical (PEC) water splitting. 67 23PDF Image | China solar seawater battery
